锂电池治理芯片 BMS AFE
VSport官网提供BMS AFE产品，可支持电池电压丈量、温度丈量、电池平衡、异常检测和；，以及菊花链通讯等多种职能，为储能利用提供完整且靠得住的支持。
产品选择器
15 个了局
Loading
|
Part No
|
Max Supported Cells
|
Supported Line Voltage, V
|
Total Measurement Error, mV
|
No. of ADC
|
ADC Resolution, bit
|
Measurement Time, μs
|
Passive Cell Balanceing Current, mA
|
No. of GPIO
|
Sleep Current, μA
|
Daisy Chain Support
|
Max Daisy Chain Rate
|
Daisy Chain Direction
|
Package
|
Temperature Range, degC
|
MOQ（PCS）
|
Comments
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 18 | 16~99 | 2 | 3 | 16 | 290 | 200 | 9 | 9 | Y | 1Mbps | Bi-direction | LQFP-64 | -40~125 | 3000 | ||
| 16 | 4.7~80 | 5 | 2 | 16 | 1000 | 80 | NA | 53 | Not support | Not support | Not support | TQFP-48 | -40~125 | 3000 | I2C/CRC Disable/LDO1 Disable | |
| 16 | 4.7~80 | 5 | 2 | 16 | 1000 | 80 | NA | 53 | Not support | Not support | Not support | TQFP-48 | -40~125 | 3000 | SPI/CRC Enable/LDO1 Disable | |
| 16 | 4.7~80 | 5 | 2 | 16 | 1000 | 80 | NA | 53 | Not support | Not support | Not support | TQFP-48 | -40~125 | 3000 | I2C/CRC Enable/LDO1 3.3 V | |
| 16 | 4.7~80 | 5 | 2 | 16 | 1000 | 80 | NA | 53 | Not support | Not support | Not support | TQFP-48 | -40~125 | 3000 | SPI/CRC Enbale/LDO1 5 V | |
| 16 | 4.7~80 | 5 | 2 | 16 | 1000 | 80 | NA | 53 | Not support | Not support | Not support | TQFP-48 | -40~125 | 3000 | SPI/CRC Enable/LDO1 3.3 V | |
| 10 | 4.7~80 | 5 | 2 | 16 | 1000 | 80 | NA | 53 | Not support | Not support | Not support | TQFP-48 | -40~125 | 3000 | I2C/CRC Disable/LDO1 Disable | |
| 10 | 4.7~80 | 5 | 2 | 16 | 1000 | 80 | NA | 53 | Not support | Not support | Not support | TQFP-48 | -40~125 | 3000 | SPI/CRC Enable/LDO1 Disable | |
| 10 | 4.7~80 | 5 | 2 | 16 | 1000 | 80 | NA | 53 | Not support | Not support | Not support | TQFP-48 | -40~125 | 3000 | I2C/CRC Enable/LDO1 3.3 V | |
| 10 | 4.7~80 | 5 | 2 | 16 | 1000 | 80 | NA | 53 | Not support | Not support | Not support | TQFP-48 | -40~125 | 3000 | SPI/CRC Enbale/LDO1 5 V | |
| 10 | 4.7~80 | 5 | 2 | 16 | 1000 | 80 | NA | 53 | Not support | Not support | Not support | TQFP-48 | -40~125 | 3000 | SPI/CRC Enable/LDO1 3.3 V | |
| - | - | - | - | - | - | - | - | Y | 1Mbps | Bi-direction | QFN16 | -40~125 | 3000 | ISOLATION SPI BRIGE CHIP | ||
| - | - | - | - | - | - | - | - | Y | 2.5Mbps | Bi-direction | QFN16 | -40~125 | 3000 | ISOLATION SPI BRIGE CHIP | ||
| - | - | - | - | - | - | - | - | Y | 1Mbps | Bi-direction | MSOP16 | -40~125 | 3000 | ISOLATION SPI BRIGE CHIP | ||
| - | - | - | - | - | - | - | - | Y | 2.5Mbps | Bi-direction | MSOP16 | -40~125 | 3000 | ISOLATION SPI BRIGE CHIP |
